Product Introduction:
• GT-12090CS rectangular TMC shower tray
• Nominal 1200 × 900 mm tray footprint
• 304 stainless steel drain cover specification
• White finish; confirm approved surface pattern
• Verify drain, trap and height against drawings
• Sample approval for finish and accessories
• OEM labels and bulk packaging by quotation
Send Inquiry
Add To Inquiry
Description
Technical Parameters
GT-12090CS / TMC shower tray

1200 × 900 mm TMC Shower Tray with a 304 Stainless Steel Drain Cover

Our GT-12090CS is a rectangular TMC shower tray specified at 1200 × 900 mm, with a white finish and a 304 stainless steel drain cover. It is intended for residential bathrooms and accommodation projects where the tray footprint, drain position and installation build-up can be matched to the site. Before bulk purchasing, confirm the approved finish, complete external height, drain connection, surface performance and supplied accessories for the exact order configuration.

GT-12090CSProduct model
1200 × 900 mmListed length × width
TMC + 304 SSTray material and drain cover
Construction and supplied parts

Match the Tray Body, Surface and Drain Cover as One Assembly

GT-12090CS combines a molded TMC tray body with a rectangular drain-cover design. For accurate procurement, the finish and drain-cover material must be considered separately from the waste outlet and plumbing trap. A 304 stainless steel cover specification does not by itself establish waste-pipe diameter or include a compatible trap.

  • Tray: molded TMC composite with a nominal 1200 × 900 mm plan size.
  • Cover: specified 304 stainless steel drain cover; check its length, fixing method and replacement access.
  • Finish: white / white-pattern appearance; approve a physical sample or controlled color reference for the selected option.
  • Connection: obtain the drain position, outlet opening and underside clearance drawing before approving the installation.

For other shapes and sizes, browse our shower tray product range.

GT-12090CS white-pattern TMC shower tray with a long rectangular drain-cover opening in a three-quarter top view
GT-12090CS tray overviewConfirm final surface pattern, drain-cover finish and location against the approved product sample.
Technical specifications

GT-12090CS Specification and Drawing Checklist

The purchasing specification must identify the physical tray, drainage components and packing unit. Values not established by the published dimensions should be taken from the approved production drawing and order documents.

Item GT-12090CS specification / order confirmation
Model GT-12090CS
Product Rectangular shower tray with drain-cover assembly
Tray body TMC (Thick Molding Compound) composite
Nominal length × width 1200 × 900 mm
Height, edge profile and underside support Confirm sectional drawing, finished overall height, bearing points and tolerances
Drain-cover material 304 stainless steel; cover dimensions and fit to be confirmed
Drain position and waste outlet Rectangular central drain-cover area in product images; confirm centerlines, opening size, trap and pipe interface
Surface / color White-family finish; approve whether plain matte white or white with grey veins for this order
Slip performance and load rating Request test conditions and model-specific report before specifying a rating or project load
Package scope Tray and agreed drain-cover components; confirm manual, waste trap, seals, protective packaging and carton quantity
Other finishes or sizes Discuss available series variants separately; do not substitute another size or finish without an approved SKU

Technical drawings should state measurement datums, overall height, permitted tolerance, drain-center coordinates and which accessories are supplied with the tray.

Bathroom and project compatibility

Will a 1200 × 900 mm GT-12090CS Fit Your Shower Area?

GT-12090CS white marble-effect shower tray installed between grey tiled walls with a central rectangular drain feature
Tiled-shower applicationCheck finished wall clearance, enclosure fixing positions and drain access before approval.

A 1200 × 900 mm footprint is only the first installation check. The final fit also depends on finished wall surfaces, available floor depth, waste-pipe position and how the shower screen meets the tray edges.

Site dimensions the buyer should provide

  • Finished length and width of the shower space, with wall-tile build-up allowed for.
  • Drain centerline measured from two fixed finished-wall references.
  • Depth available for the tray support and compatible waste trap.
  • Door opening direction, glass enclosure footprint and edge-sealing detail.
  • Floor construction, waterproofing plan and expected accessibility threshold.

Do not approve as a direct replacement when the existing trap cannot line up, the substrate lacks the required support, or a level-access design lacks a confirmed waterproofing and floor-detail specification.

Surface and drain inspection

Approve the White Finish and Drain Detail Before Bulk Supply

For projects using repeated bathrooms, the appearance of the installed tray needs the same scrutiny as dimensional fit. The photographed GT-12090CS configuration has a white surface with grey stone-like veining. If a uniform white finish is required, request an approved sample and confirm which surface version is included in the quotation.

  • Inspect color and vein/pattern consistency under the project lighting conditions.
  • Verify cover seating, removal method and access for cleaning the drain.
  • Confirm whether the quotation includes the waste trap or only the visible 304 stainless steel cover.
  • Check surface-cleaning instructions and any required wet-slip evidence against project specifications.

For materials and test requirements, the BSI reference for BS EN 14527 shower trays describes the scope of testing for domestic-purpose trays. Compliance must be established using documentation applicable to the actual model and intended market.

GT-12090CS white veined shower tray with central rectangular drain cover installed in a dark tiled bathroom
White patterned surface and drain layoutApprove the production finish and cover detail with the order sample.
Alternative shower tray SKUs

Compare the GT-12090CS with Other ZIAX Shower Trays

Different shower tray series can use different tray materials, finishes, depths and waste configurations. Choose the alternative based on the project drawing, not on a similar product photo.

Model / product Product direction Key selection difference
GT-12090CS TMC, nominal 1200 × 900 mm, 304 SS drain cover Current white or patterned-white tray configuration
GT-12090ES stone tray Stone-effect, non-slip series Compare surface specification, approved size and drainage parts
GT-12080ES slate stone tray 1200 × 800 mm listing in an SMC/TMC stone-effect series Narrower nominal footprint; do not assume identical drain and height
SMC slate stone tray, white finish SMC-family white-finish shower tray Confirm product model, surface, waste assembly and availability

Compare all available shower tray configurations before changing an approved project schedule.

Quality assurance and purchasing evidence

Inspection Points for a GT-12090CS Production Order

GT-12090CS shower tray with white veined surface and rectangular drain installed in a blue tiled shower cubicle
Installed drain and perimeter arrangementInclude floor waterproofing, wall joint and outlet alignment in project acceptance checks.

We can review incoming material identification, finished geometry, cover condition and shipment handling against an agreed purchase specification. A factory inspection plan should define which checks are performed, how samples are chosen and what records accompany the order.

Material and appearance

Approved TMC formulation reference, surface color sample and cover material identification.

Dimensions and fit

Length, width, height, flatness, edge structure and drain-center alignment against the drawing.

Functional checks

Drain-cover fit, water flow and leak-sensitive interfaces under an agreed test setup.

Shipment condition

Protective inserts, edge/corner protection, carton labels and visible damage checks.

Product-specific test reports, conformity documents, slip-resistance classifications and load ratings should be checked against their stated model, test method, sample configuration and validity. Management-system certificates alone do not establish shower tray performance.
OEM, packing and quotation

Coordinate GT-12090CS Samples, Finish Approval and Bulk Packaging

As a China-based sanitaryware manufacturer, we can discuss GT-12090CS orders with importers, distributors and project buyers. For an OEM supplier arrangement, the key handoff is an approved product specification that both the factory and purchasing team can use consistently.

01Confirm drawing

Model, external dimensions, height, drain position and project installation limits.

02Approve sample

Surface/color, drain-cover configuration, slip evidence and accessories.

03Set OEM scope

Discuss logo, labels, finish, packaging and any design/tooling changes.

04Release purchase

Agree quantity, carton protection, inspection criteria, destination and schedule.

Color changes, custom mold work, private labeling and packing formats depend on the agreed configuration and order volume. Share artwork and target project specifications so feasibility, sample timing, MOQ and lead time can be confirmed in the quotation.

Learn more about ZIAX manufacturing and OEM cooperation or contact our sales team with your purchasing requirements.

GT-12090CS model quotation

Request a Shower Tray Drawing and Bulk Quotation

Send model GT-12090CS, required finish, order quantity, destination country, finished-shower dimensions, drain/waste interface drawings, any project test requirements, and OEM logo or packing instructions. Include the installation drawing when the tray must fit an existing wet-area design.

Send GT-12090CS Purchase Requirements
GT-12090CS product questions

Frequently Asked Questions

What are the dimensions of GT-12090CS?+

The nominal listed length and width are 1200 × 900 mm. Confirm finished height, edge thickness, drain coordinates, tolerances and installation clearance from the approved dimensioned drawing.

Is the GT-12090CS drain cover made from 304 stainless steel?+

The GT-12090CS listing specifies a 304 stainless steel drain cover. Cover thickness, fastening, waste outlet, trap and replacement part scope should be confirmed for the ordered configuration.

Can this tray replace an existing 1200 × 900 mm shower base?+

Only after matching the finished space, wall joints, tray support, outlet position, trap depth and enclosure details. Equal length and width do not guarantee drain or installation compatibility.

Is the finish plain white or white with grey marble-like veins?+

GT-12090CS is offered as a white TMC shower tray, while product images also depict grey stone-like veining. Specify the requested appearance and approve a sample before ordering multiple units.

Are the waste trap and installation accessories included?+

The tray listing includes a stainless steel drain cover. Confirm the exact packing list and whether the waste trap, seals, installation guide, threshold strip or flange are supplied or separately quoted.

Can GT-12090CS be ordered with an OEM color, label or packaging?+

Share the target color reference, logo files, carton design, quantity and delivery destination. We can review feasible options and confirm sample, tooling, MOQ and lead-time conditions for the requested order.

What test or compliance records can be reviewed before ordering?+

State the destination-market requirements and request evidence identifying the tested model, edition of the applicable standard, slip method, load conditions and report scope. Availability and suitability of documentation should be confirmed before order release.

For related sourcing choices, review ZIAX shower trays and our GT-12080ES product details.
