| Item | Specification |
|---|---|
| Product Name | AVA adaptiveSense® Urinal Sensor Flusher URFL-A511 |
| Sensor Technology | Time-of-Flight (ToF) |
| Detection Method | Distance Measurement |
| Power Supply | 4 × AA Alkaline Batteries / 6V DC |
| Operating Current | ≤44 μA |
| Detection Distance | 40 cm / 50 cm / 60 cm (Default: 50 cm) |
| Flush Volume | 0.3L / 0.5L / 0.7L / 1.0L / 1.3L |
| Default Flush Volume | 0.5L |
| Water Pressure | 0.1 – 1.0 MPa |
| Water Inlet | G1/2" |
| Installation Thickness | 9–16 mm |
| Indicator | LED Indicator & Illuminated Logo (selected models) |
| Housing Materials | ABS |
| Available Shapes | Oblong |
| Available Colors | Yellow |
Features Summary & Benefyts
Detection Distance
Flush Volume
Overuse Detection (Stadium Mode)
Cleaning Mode
Change Settings Mode
Flushing Flow Regulation
AVA adaptiveSense® Touchless Urinal Sensor Flusher
The AVA adaptiveSense® Urinal Sensor Flusher is a next-generation touchless flushing solution powered by Time-of-Flight (ToF) sensing technology. Unlike conventional infrared (IR) sensors, adaptiveSense® delivers precise distance measurement, stable performance, and intelligent detection that adapts to different installation environments.
Designed for commercial restrooms, public facilities, hotels, airports, hospitals, office buildings, and other high-traffic applications, the system provides hygienic hands-free operation while reducing false triggering and optimizing water consumption.
The programmable adaptiveSense® platform allows installers to easily adjust sensing distance, flush volume, sensitivity, and operating modes without changing firmware, making one hardware platform suitable for multiple projects.
Production Details
1. Intelligent ToF Sensing Technology
Powered by Time-of-Flight (ToF) Sensor Technology, the AVA Urinal Sensor Flusher delivers highly accurate distance detection with millimeter-level precision. Unlike traditional Infrared Urinal Flushers, the adaptiveSense® platform minimizes false activation caused by ambient light, surface color, or environmental conditions. Adjustable sensing distance and programmable flushing settings make this Touchless Urinal Flusher ideal for commercial restroom projects that demand reliable performance, water efficiency, and long-term stability.
SEO Keywords: Urinal Sensor Flusher, Touchless Urinal Flusher, Automatic Urinal Flusher, ToF Sensor Technology, Touchless Flush System
2. Easy Installation & Maintenance
Designed for professional installation, the modular structure allows quick access to the power module and solenoid valve without removing the urinal from the wall, significantly reducing maintenance time. Supporting both battery and DC power options, the Commercial Urinal Flusher also features adjustable flush volume, hygiene auto flush, and customizable operating modes, making it a flexible Sensor Urinal Flush Valve solution for airports, hotels, office buildings, hospitals, and other high-traffic commercial washrooms.
SEO Keywords: Commercial Urinal Flusher, Sensor Urinal Flush Valve, Automatic Flush Valve, Water Saving Urinal Flusher, Touchless Restroom Solutions
FAQ
Q: Can the sensing distance be adjusted?
A: Yes. Depending on the model, the sensing range can be adjusted during installation to provide reliable performance for different restroom layouts and user requirements.
Q: Can the sensor help save water?
A: Yes. The automatic urinal flusher only activates when needed, reducing unnecessary flushing and helping lower water consumption while maintaining restroom cleanliness.
Q: Is the sensor resistant to water and humidity?
A: Yes. The touchless urinal sensor is designed for restroom environments and features a durable, moisture-resistant construction that ensures stable long-term operation.
